How Java's Concurrency APIs Fit Together

A concurrency problem can begin with an ordinary requirement: let two independent operations make progress without forcing one to wait for the other. The requirement is easy to state. Choosing among Thread, ExecutorService, Future, CompletableFuture, locks, atomics, queues, and synchronizers is harder when they look like competing answers to the same question.

These APIs answer different questions. Some describe work, some decide how it runs, some represent results, and others protect shared state or coordinate tasks. Grouping them by responsibility turns the standard library from a list of names into a map.

We will build that map around a small customer-dashboard example, then use shorter examples for the problems the dashboard does not cover. The examples assume basic Java, not prior concurrency knowledge. Start with the responsibility the program needs; choose the class after that.

Start with a program that waits twice#

Suppose an endpoint builds a customer dashboard from a profile and a list of recent orders:

var profile = loadProfile();
var orders = loadOrders();

return new Dashboard(profile, orders);

The code fragments below omit imports and surrounding class definitions when those details do not affect the concurrency mechanism.

The second call starts after the first one returns. If the operations are independent and spend most of their time waiting for remote services, that order leaves an obvious opportunity: start both, then assemble the dashboard when both results are available.

That small change already involves three separate responsibilities: describe each operation, decide how to execute it, and obtain its result. The full map uses seven questions:

These groups overlap. CompletableFuture, for example, represents a result and can also arrange dependent execution. Treat the groups as questions for locating a problem rather than rigid boxes for classifying every type.

On a first pass, focus on tasks, executors, futures, and the shared-state sections. Learn queues and semaphores as named solutions for handoff and limits. Leave CyclicBarrier, fork/join, and continuation-scheduling rules as landmarks until a program gives you one of those problems.

One vocabulary distinction will help throughout the map. Concurrent tasks make progress during overlapping periods; they do not have to execute at the same instant. Parallel work does execute at the same instant. A single CPU core can interleave concurrent tasks, while parallel execution requires hardware resources that can run work simultaneously. We will use concurrency for the waiting-heavy dashboard and reserve parallel computation for a separate data-processing example.

Tasks describe work#

A task describes work. A thread is one possible execution mechanism.

Java’s basic task interfaces make that separation visible. Runnable represents an operation with no result,¹ while Callable<V> returns a value and may throw an exception.² Neither interface chooses the thread that will run it. Their contracts only describe the operation.

Runnable refreshCache = () -> cache.refresh();

Callable<String> loadProfile =
        () -> profileClient.fetchProfile(customerId);

Creating either value does not start the work. A caller could invoke run() or call() directly, or it could hand the task to an executor. That later choice determines the execution policy.

The code that describes a cache refresh stays unchanged whether the application runs it immediately, schedules it in a pool, or starts a virtual thread for it.

Use Thread directly when the program intentionally owns one thread’s identity or lifecycle, such as naming it, installing its uncaught-exception handler, or joining that specific thread. An executor is the better fit when thread creation, scheduling, and lifecycle belong to an execution policy rather than the task itself.³

Executors decide how work runs#

An Executor receives a Runnable and applies an execution policy. Its interface separates task submission from details such as thread creation, reuse, and scheduling. The Executor contract does not promise asynchronous execution: a minimal executor is allowed to call command.run() in the submitting thread, while other implementations create threads or reuse them from a pool.⁴

ExecutorService adds lifecycle operations and methods such as submit, which returns a Future.⁵ An application should close or shut down an executor service when it no longer needs it. In modern Java, the interface is AutoCloseable, so a try-with-resources block can own that lifecycle.

The executable examples target Java 21 or newer because they use virtual threads; the responsibility map and the older APIs apply more broadly. Here is the dashboard using one virtual thread per submitted task:

Dashboard loadDashboard() throws Exception {
    try (var executor = Executors.newVirtualThreadPerTaskExecutor()) {
        Future<String> profile =
                executor.submit(this::loadProfile);
        Future<List<String>> orders =
                executor.submit(this::loadOrders);

        return new Dashboard(profile.get(), orders.get());
    }
}

Both tasks are submitted before the code waits for either result. Their executions can therefore overlap when the executor can run them concurrently. Submission alone is not a guarantee of overlap; the executor owns that policy and may be constrained by available resources.

The following order prevents the two dashboard operations from overlapping:

var profile = executor.submit(this::loadProfile).get();
var orders = executor.submit(this::loadOrders).get();

The first get() may block before the second line can submit loadOrders. Keep the handles first and the waits after both submissions when the operations are independent.

Virtual threads became a final feature in Java 21. They are Thread instances scheduled by the JDK rather than permanent one-to-one wrappers around operating system threads. They suit thread-per-task code with many concurrent operations that often wait, which describes calls to remote services. They do not make CPU-bound code run faster or make timing-dependent access to shared mutable state safe. JEP 444 also advises against pooling virtual threads.⁶ Create one per task; use a separate mechanism when a scarce resource needs a concurrency limit.

Results can be waited for or composed#

A Future<V> is a handle to a result that may not exist yet. get() waits when necessary and then returns the value or reports the computation’s failure. A Future also exposes completion status and cancellation. Under the Future contract, cancel(...) attempts cancellation; already-running work may continue, depending on timing and whether the task responds to interruption.⁷

The dashboard example uses two plain futures because its control flow is short: submit two operations, wait for both, and build one value. The blocking get() calls do not erase the earlier concurrency because both submissions already happened.

CompletableFuture<T> becomes useful when later work should depend on earlier results. It implements both Future<T> and CompletionStage<T>, which adds operations for transforming and combining completed stages.

Start with one result and one transformation:

CompletableFuture<String> profile =
        CompletableFuture.supplyAsync(this::loadProfile, executor);

CompletableFuture<String> label =
        profile.thenApply(name -> "Customer: " + name);

After profile completes normally, thenApply passes its result to the function and produces another stage containing the label. No get() separates the two steps.⁸

If we translated the earlier two-input dashboard directly, CompletableFuture would mostly look like a syntax swap around the same fixed fan-out. Add one real dependency instead: recommendations can start only after the profile is available, while orders can still load independently.

profile + orders ----------> dashboard -------------\
profile -------------------> recommendations --------+--> personalized dashboard

The code mirrors that dependency graph:

try (var executor = Executors.newVirtualThreadPerTaskExecutor()) {
    CompletableFuture<String> profile =
            CompletableFuture.supplyAsync(this::loadProfile, executor);
    CompletableFuture<List<String>> orders =
            CompletableFuture.supplyAsync(this::loadOrders, executor);

    CompletableFuture<List<String>> recommendations = profile.thenCompose(
            loadedProfile -> loadRecommendations(loadedProfile, executor));

    CompletableFuture<Dashboard> dashboard =
            profile.thenCombine(orders, Dashboard::new);

    return dashboard.thenCombine(
                    recommendations,
                    (loadedDashboard, loadedRecommendations) ->
                            new PersonalizedDashboard(
                                    loadedDashboard.profile(),
                                    loadedDashboard.orders(),
                                    loadedRecommendations))
            .join();
}

The asynchronous suppliers receive the executor explicitly because CompletableFuture async methods without one normally use ForkJoinPool.commonPool().⁸

profile and orders start independently. After profile completes normally, thenCompose invokes the recommendation function and flattens the CompletableFuture it returns. The first thenCombine builds a dashboard after both independent inputs arrive. The second combines that dashboard with the recommendations, and join() waits once at the request boundary.

Plain Future and CompletableFuture overlap, but they encourage different control flow. Plain Future remains adequate for a short, fixed set of independent tasks when the caller can submit them together and wait at one clear boundary. Completion stages help when one result starts later work or several branches must converge. The example stops at composition. Production code still needs an explicit policy for errors, cancellation, timeouts, and executor ownership.

Shared state has three separate questions#

Choosing an executor does not make shared mutation safe. Imagine adding a counter that every completed dashboard task increments:

volatile int completed;

void markCompleted() {
    completed++;
}

The volatile declaration gives reads and writes memory-consistency guarantees, but completed++ is a compound read-modify-write operation. Two threads can read the same value and both write the same incremented value, losing one update. The Java Language Specification separates these memory actions,⁹ and the atomic package supplies operations that perform the complete update atomically.

Shared-state safety involves three separate questions:

• Atomicity: must other threads observe a group of operations as one indivisible action?
• Visibility: when one thread writes a value, what guarantees that another thread sees it?
• Ordering: what constrains the order in which actions become observable across threads?

Consider a one-time handoff in which one thread publishes a dashboard and another reads it:

Dashboard publishedDashboard;
volatile boolean dashboardReady;

void publish(Dashboard value) {
    publishedDashboard = value;
    dashboardReady = true;
}

Dashboard readIfReady() {
    return dashboardReady ? publishedDashboard : null;
}

The dashboard write occurs before the volatile flag write in the publishing thread. If another thread later reads dashboardReady as true, the Java Memory Model’s volatile happens-before rule makes the earlier dashboard write visible to that reader.¹⁰ The flag does not lock either method or make a compound update atomic.

synchronized can provide mutual exclusion for a critical section and a visibility relationship around the same monitor. When one thread unlocks a monitor, that action happens-before a later lock of the same monitor, so writes before the unlock become visible through that synchronization relationship. The java.util.concurrent memory-consistency summary also documents similar guarantees for task submission, successful Future.get(), concurrent collections, and synchronizers.¹¹

volatile provides visibility and ordering for reads and writes of one field. It does not provide mutual exclusion around a sequence such as an increment. The Lock interfaces provide explicit locking plus options such as interruptible or timed acquisition and multiple conditions.¹² That flexibility comes with explicit acquire/release code and does not make Lock an automatic upgrade over synchronized.

For one independent counter, AtomicInteger matches the operation directly:

AtomicInteger completed = new AtomicInteger();

Future<Integer> task =
        executor.submit(completed::incrementAndGet);

The java.util.concurrent.atomic package provides thread-safe read-modify-write operations on single variables, including increment and compare-and-set.¹³ One atomic variable does not make a multi-value invariant atomic. If a rule spans a balance and a ledger entry, or requires several objects to change together, a lock around the invariant or a design that avoids shared mutation may fit better.

Concurrent collections protect documented operations#

Shared data often needs more structure than one counter. Java supplies concurrent maps, queues, deques, and other collections with documented safety and consistency guarantees. That protection applies to their operations. It does not turn any sequence written by the caller into one atomic action.

Consider a cache registration backed by a ConcurrentHashMap:

if (!cache.containsKey(customerId)) {
    cache.put(customerId, loadCustomer(customerId));
}

Even with a concurrent map, another thread can change the map between the check and the put. ConcurrentMap supplies compound operations such as putIfAbsent, compute, and merge for transitions covered by their contracts:¹⁴

cache.computeIfAbsent(customerId, this::loadCustomer);

Use one of those operations when its documented semantics match the state change. An invariant that spans several map entries or external side effects still needs a larger design. ConcurrentHashMap documents the guarantees and restrictions of its computeIfAbsent implementation.¹⁵

BlockingQueue solves another shared-data problem: handing items from producers to consumers.¹⁶ Its operations let a producer fail immediately, wait for space, or wait up to a timeout; a consumer has corresponding choices when the queue is empty. Capacity depends on the implementation. ArrayBlockingQueue is bounded, while other implementations may be unbounded or have different handoff semantics.

BlockingQueue<Job> jobs = new ArrayBlockingQueue<>(100);

jobs.put(new Job(customerId)); // waits when this bounded queue is full
Job next = jobs.take();        // waits when it is empty

The queue owns safe transfer of each element. The Job object may still need its own safe design if producers and consumers mutate it after handoff.

Coordination describes who may proceed#

A two-request dependency limit is a coordination policy. A semaphore represents that policy with permits:

String fetchWithLimit(Semaphore permits, String requestId)
        throws InterruptedException {
    permits.acquire();
    try {
        return dependency.fetch(requestId);
    } finally {
        permits.release();
    }
}

Constructing new Semaphore(2) lets at most two successful acquisitions proceed at once. The finally block returns the permit when the call completes or fails. The virtual-thread executor used earlier creates a new virtual thread per task and does not impose a thread-count bound. JEP 444 recommends keeping that model and using a semaphore to represent the actual limit on a scarce service.⁶

Other synchronizers encode other policies. A CountDownLatch lets tasks wait until a count reaches zero, which fits a one-time startup gate. A CyclicBarrier coordinates a group that must all reach the same phase before continuing. A BlockingQueue coordinates through data availability and capacity. The java.util.concurrent synchronizer overview groups these APIs by policy.¹⁷

These policies do not protect every object touched by the participating tasks. The semaphore limits calls in the example; it says nothing about the thread safety of dependency or other shared state. Use a synchronizer when the rule concerns who may proceed, and analyze shared invariants separately.

Parallel computation splits data or work#

The dashboard spends time waiting. A sum over a large collection presents a different problem: divide computation over data and combine the partial results.

ForkJoinPool is an ExecutorService built around work-stealing and tasks that can split into smaller tasks. Its contract does not guarantee compensating threads for blocked I/O or unmanaged synchronization.¹⁸ Do not treat a fork/join pool as the default executor for many blocking network calls. It is a better conceptual fit for decomposable computation than for replacing the waiting-oriented dashboard executor.

Parallel streams expose data-parallel execution through the stream API:

long sum = values.parallelStream()
        .mapToLong(value -> (long) value * value)
        .sum();

This reduction follows the java.util.stream requirements because the mapping is stateless, it does not modify the source, and addition is associative.¹⁹ Those properties allow the stream implementation to partition work and combine partial results safely. Stateful operations, encounter-order requirements, coordination overhead, small inputs, and the available processors can change the tradeoff. Calling parallelStream() does not promise a speedup.

Measure a representative workload before choosing parallel execution for performance. The appropriate comparison includes the real data size, operation cost, ordering requirements, and environment. A tiny example can prove behavior; it cannot establish that production code will run faster.

Choose the responsibility before the class#

Start with the sentence that describes the problem. Let the API name come second.

After choosing the responsibility, evaluate lifecycle, failure policy, workload, contention, ordering, and resource limits before selecting the concrete API.

As a practice exercise, return to the dashboard and write five sentences before changing its code: which operations are independent, what results they produce, where waiting is acceptable, what state they share, and which dependency limits must survive higher concurrency. Each answer points to one part of the map and to the next piece of documentation or testing the program needs.
